Cohline 2240 R9 Specification Rubber Fuel Injection Hose (10mm ID) E85 Compatible by Cohline

Code IH-010E
£0.00
£17.32
Click the image to enlarge
Code IH-010E
In stock: 8
£0.00
£17.32
Save
Earn 0 reward points with this product.

Sorry we're out of stock!

Enter your email address below and we’ll notify you as soon as it becomes available.

  • Description

    Cohline 2240 R9 Specification Rubber Fuel Injection Hose (10mm Push On) E85 CompatibleWith the rise in ethanol and other additives percentage in petrol, the R9 specification hose is the only one you should consider when replacing existing hose.

    NOTE: Priced Per Metre.

    By using a lower specification may result in premature ageing of the hose.

    Application:

    • Petrol (In Mixture With):
      • Methanol (Allowed Content 0-100%).
      • Ethanol (Allowed Content 0-100%).
      • Butanol (Allowed Content 0-100%).
    • Diesel (In Mixture With):
      • Rapeseed Methyl Ester (Allowed Content 0-100%).
      • Hydro Treated Vegetable Oil (Allowed Content 0-100%).
      • Fatty Acid Methyl Ester (Allowed Content 0-100%).
      • Siya Methyl Ester (Allowed Content 0-100%).

    Hose Construction:

    • Inner Layer - FKM.
    • Intermediate Layer - ECO.
    • Reinforcement - Aramid.
    • Outer Layer - ECO.

    Dimensions & Pressure:

    • Inner Diameter - 9.3mm.
    • Outer Diameter - 15.3mm.
    • Working Pressure - 10 Bar.
    • Testing Pressure - 20 Bar.
    • Burst Pressure - 50 Bar.
    • Smallest Bend Radius - 60mm.
    • Working Temperature -40 Deg C to +125 Deg C.

    Additional Standards:

    • BMW GS93010.
    • DBL 6257.70.
    • GME 08007.
    • SAE J30R9.
    • VW TL52424.
